Rated input power:1300 W

Drill Ø steel:16 / 10 mm // 5/8 / 3/8 "

Drill-Ø soft wood:40 / 25 mm // 1 9/16 / 1 "

No-load speed:0 - 1100 / 0 - 3100 rpm

Maximum torque:44 / 16 Nm // 390 / 142 in-lbs

• Selectable "impuls" mode for removal of stubborn screws and for spot-drilling on smooth surfaces
• Robust die cast aluminium gear housing for optimum heat dissipation and durability
• Rotating carbon brush bridge for maximum performance even in anti-clockwise operation, e.g. for the removal of stubborn screws
• Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
• Thumbwheel for speed preselection
• Two-speed gearbox
• Metabo Marathon motor with patented dust protection for long service life
• Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
• Forward and reverse rotation
• Spindle with hexagonal recess for screwdriver bits for working without chuck
• Overload protection: protects the motor from overheating
• Restart protection: prevents unintentional start-up after power supply interruption
• Handle with non-slip soft-grip surface
• Cable-protecting ball joint for optimal freedom of motion when working
• Wear Indication for Carbon Brush

The machine shown may differ in equipment and technical details depending on the configuration.
Kindly pay attention to delivery scope and product description.
Accessories included only if listed in the delivery scope.

Characteristics

Rated input power1300 W

Output power730 W

Drill Ø steel16 / 10 mm // 5/8 / 3/8 "

Drill-Ø soft wood40 / 25 mm // 1 9/16 / 1 "

No-load speed0 - 1100 / 0 - 3100 rpm

Revolutions at rated load1100 / 3100 rpm

Gears2

Maximum torque44 / 16 Nm // 390 / 142 in-lbs

Collar diameter43 mm / 1 11/16 "

Chuck capacity1.5 - 13 mm // 0.059 - 0.512 "

Drill spindle with hexagonal recess6.35 mm / 1/4 "

Drill spindle thread1/2 " - 20 UNF

Weight (without power cable)2.7 kg / 6 lbs

Cable length4 m / 13 ft

Vibration

Drilling in metal4.2 m/s²

Uncertainty of measurement K1.5 m/s²

Noise emission

Sound pressure level84 dB(A)

Sound power level (LwA)95 dB(A)

Uncertainty of measurement K3 dB(A)

• Geared chuck
• Chuck key
• Side handle

Product Code: BEV1300-2
